GPON Gateway

Enterprise-level GPON Gateway

GPON/EPON ONT, the enterprise-level gateway, is the core interconnection device of enterprise networ...

  • 产品概述
  • 功能特性
  • 技术参数
  • 组网应用
  • 相关资料
GPON/EPON ONT, the enterprise-level gateway, is the core interconnection device of enterprise network. As a PON enterprise gateway for small and medium-sized enterprises, the product provides routing and security management functions, integrates optical modem + routing + fixed-line + industry convergence application, and have SD-WAN access and VPN tunnel capabilities, and automatically delivers all services through one optical fiber, meeting various information requirements such as enterprise communication, office, and entertainment.
These series support cloud platform access and establish a VxLAN tunnel as the cloud access terminal for SDN controller.
Users can flexibly deploy multiple services on the platform to reduce the network operation and maintenance costs.

High-speed broadband access

Support uPON  (EPON/GPON self-adaptative), support multiple Gigabit Ethernet ports, WAN/LAN switching

ntegration of basic functions

Integrate data, routing, wireless, VPN, VXLAN, firewall, voice etc.

Multiple voice protocols

Support voice access of IMS/NGN network

support IETF SIP and ITU-T H.248 protocol

supports common voice features

Flexible wireless access

Support the business issued automatically, local WEB management, and SNMP/TR069 remote network management.

Cloud network unified terminal

Support to be used as uCPE node for cloud network communication, supports enterprise cloud business access by IPSec VPN and VxLAN


Hardware

Model

SDG1800M-G

OfficeTen1800-G4S4

SDG1800M-U

OfficeTen1800-G8S8

WAN

1×EPON/GPON self-adaptive interface,Class B+

LAN

4GE

8GE

FXS

0

4

16

8

Power supply

12V/1A

12V/1.5A

110V-240V


12V/2A

Power Consumption

7W

18W

35W

22W

Dimension (L*W*H/mm)

142*119*28

212*148*26

440*210*43.5


234*179*43.5

WiFi

IEEE802.11b/g/n and Mixed Working mode
IEEE802.11 ac/ax optional
2×2 MIMO, 2.4/5Ghz, 2× external 5dBi antennas

USB

1× USB2.0

Enclosure

Metal material

Reliability

7 x 24 hours, MTBF> 50000 hours

Temperature and humidity

-5℃55℃<95%non -condensation


Software Function

ACCESS FUNCTION

Supports bridging, routing, and mixed working modes. Supports DHCP Server, DNS, NAT, routing, EoIP, NTP, VLAN, and multicastetc.

Multicast

Support multicast IGMP Snooping and IGMP Proxy

Speed limit

Support port speed limit, and QoS speed limit

Routing

Support static routing,policy routing,and route backup

IPv4/IPv6

Supports IPv4/IPv6 dual-stack, IPv6 address management, IPv6 data forwarding, and IPv6 DNS resolution

VPN

Supports L2TP VPN, IPSec VPN, Netconf VxLAN VPN and PPTP VPN

QoS

Supports rate limiting based on vlans, IP address segments, ports, and protocols. Support 802.1P and DSCP tags for traffic. Traffic priorities can be set to ensure the bandwidth of critical services

Security

Supports basic firewall, website filtering, MAC address filtering and access control, Anti ARP and DDos attacks

Voice

Support SIP,H.248 and IMS-SIP voice protocols

Support G.711a/u, G.723, G.722, G.729 voice codec

Support T.30/T.38 fax

NMS

Support local Web management, SNMP, TR069, SYSLOG remote network management
