XGPON Gateway

Enterprise-level FTTR 10G

FTTR-B is an integrated FTTR solution for enterprises, which consists of a primary gateway and a sec...

  • 产品概述
  • 功能特性
  • 技术参数
  • 组网应用
  • 相关资料

FTTR-B is an integrated FTTR solution for enterprises, which consists of a primary gateway and a secondary gateway. It effectively solves the network and WiFi coverage in a wide range of office buildings. The product has functions such as basic routing, basic firewall, and Wi-Fi. The primary gateway supports EPON/GPON/10GPON interface at the uplink, and 4GE, 4Fxs and PON port which connect multiple secondary gateways downward. The secondary gateway provides 4GE and WIFI5 for the customer. The equipment has the advantages of large coverage, high bandwidth, simple installation, flexible networking, smooth evolution, and convenient maintenance.

Reduce the cost of private line construction

Integrate functions such as data, routing, wireless, VPN, VXLAN, firewall and voice, and effectively reduce the cost of equipment procurement, deployment and maintenance


Improve network security and reliability

Support line backup, network bandwidth management, network security protection, VPN encryption and other network security functions to improve enterprise network security and reliability;



Quick open private line

Plug and play based on PON network, support EPON/GPON/10GPON, easy to implement, no complicated installation, and support unified service distribution;



Unified maintenance and management

Web-based network management interface, easy to use and maintain, realize unified construction, maintenance and management through a unified network management platform. Reduce the construction cycle of enterprise private lines;


Cloud-network fusion terminal

It can be used as a uCPE node for cloud-network fusion, which supports enterprises to access cloud services through IPSecVPN and VxLAN, and supports customized development (This feature is under development).

P/N

SDG880X-F

WAN Interface

XGPON \WAN

LAN Interface

1*GPON+1*2.5GE+3*GE

Voice interface

4FXS

WLAN

AX3000 2×2 MIMO (2.4G&5G)

USB interface

1× USB3.0 high-speed interface

Power supply

12V

Power consumption

25W

Enclosure

Metal material

Reliability

7×24 hours, > 99.999%; MTBF > 50,000 hours

Working environment

-20℃55℃; less than 95% (non-condensing)
